Project Hades Operation

The web format of this guide reflects the most current release.  Guides for older iterations are available in PDF format.

Use the following steps to install the custom objects in ThreatQ v6:

1. Download the integration bundle from the ThreatQ Marketplace.
2. Unzip the bundle and locate the custom object files.

   The custom object files will typically consist of a JSON definition file, install.sh script, and a images folder containing the svg icons.

3. SSH into your ThreatQ instance.
4. Navigate to the following location:
   cd /var/lib/threatq/misc/

   Copy Code

5. Upload the custom object files, including the images folder.

   The directory structure should be as the following:

   • misc
     • install.sh
     • <custom_object_name>.json
     • images (directory)
       • <custom_object_name>.svg
6. Run the following command:
   kubectl exec -it deployment/api-schedule-run -n threatq -- sh /var/lib/threatq/misc/install.sh /var/lib/threatq/misc

   Copy Code

   The installation script will automatically put the application into maintenance mode, move the files to their required directories, install the custom object, update permissions, bring the application out of maintenance mode, and restart dynamo.

7. Delete the install.sh, definition json file, and images directory from the misc directory after the object has been installed as these files are no longer needed.

Use the following steps to install the custom objects in ThreatQ v5:

1. Download the integration zip file from the ThreatQ Marketplace and unzip its contents.
2. SSH into your ThreatQ instance.
3. Navigate to tmp directory:
   cd /tmp/

   Copy Code

4. Create a new directory:
   mkdir hades_op

   Copy Code

5. Upload the hades.json and install.sh script into this new directory.
6. Create a new directory called images within the hades_op directory.
   mkdir images

   Copy Code

7. Upload the Cryptocurrency and Onion svg files.
8. Navigate to the /tmp/hades_op.

   The directory should resemble the following:

   • tmp
     • hades_op
       • hades.json
       • install.sh
       • images
         • crypocurrency.svg
         • onion.svg
9. Run the following command to ensure that you have the proper permissions to install the custom object:
   chmod +x install.sh

   Copy Code

10. Run the following command:
    sudo ./install.sh

    Copy Code

    You must be in the directory level that houses the install.sh and json files when running this command.

    The installation script will automatically put the application into maintenance mode, move the files to their required directories, install the custom object, update permissions, bring the application out of maintenance mode, and restart dynamo.

11. Remove the temporary directory, after the custom object has been installed, as the files are no longer needed:
    rm -rf hades_op

    Copy Code

Search Project Hades (Indicators)

The Search Project Hades action, when performed on an indicator, queries the Project Hades database for indicators of compromise.

Email Address

GET https://api.aikostek.com/v2/lookup/email

Sample Response:

{
  "data": [
    {
      "appearances": [
        "pedohubd2zi7jv5e.onion",
        "pedohub755qxwt7mpcdq3tj455aum7ejwvca2nghmejbwldgizjn4oid.onion",
        "pedohubksclx37ve.onion",
        "pedohubhsrhqwbhh.onion",
        "pedohub6lyqy7pla.onion",
        "pedohubvqv5mnxazrhv6kqzrz6ezebkugt7daro7cfsum6zfrmdtgaqd.onion",
        "pedohub2jyt2rcucrbbmrvaxrfowvvueddilwaugkowxpt3t7tznpcqd.onion",
        "udp3dseyoyfk3n4oug2c4s63rqpyaczfii3ipwgdrxpdc4pouy4u3qyd.onion",
        "pedohubj4cx2xebrvcjt3b5eoae3lxme34fj6kmwblzr3wd6ria5gfid.onion",
        "pedohubbuiyyxxh5uodpcm4yhscm6nsl2ne2skcuiwoelbuav5rffgid.onion",
        "pedohubmq66kovax642xrpwajvq4wnz3zzkr6kp6frlcjxoz5mahgyqd.onion",
        "pedohubotw4vaob3jahhxmblg73mxf7uvhbkltnr4htzl2ezemsr36yd.onion",
        "pedohubk6dvg33wjtinp7dvszec4n6lyut4p2ay46ieulolseeboksyd.onion"
      ],
      "meta": "",
      "selector": "opva.access@secmail.pro",
      "source_url": [
        "http://pedohubotw4vaob3jahhxmblg73mxf7uvhbkltnr4htzl2ezemsr36yd.onion",
        "http://pedohubotw4vaob3jahhxmblg73mxf7uvhbkltnr4htzl2ezemsr36yd.onion/index.html",
        "http://pedohub2ffxswug6w2mczstmwgnwmfhp2cdrwcdelg3t5yvtnfjjdyqd.onion",
        "http://pedohub2ffxswug6w2mczstmwgnwmfhp2cdrwcdelg3t5yvtnfjjdyqd.onion/index.html",
        "http://sw7utj33cbpsw4pywco7c6ylhajcggt4fzmlxex32bxkn5c57zix42id.onion",
        "http://sw7utj33cbpsw4pywco7c6ylhajcggt4fzmlxex32bxkn5c57zix42id.onion/index.html",
        "http://pedohubmzbd7mkbv3alsflgcmuemzo2yufwqjvr2nsntdxdnzgnsc7id.onion",
        "http://pedohub5am7icvfpr3brn2eaaagv3vtyua3iex7gj7czfm3dvfhjrnad.onion",
        "http://pedohub5am7icvfpr3brn2eaaagv3vtyua3iex7gj7czfm3dvfhjrnad.onion/index.html"
      ],
      "type": "email"
    }
  ]
}

ThreatQuotient provides the following default mapping for this action:

Feed Data Path	ThreatQ Entity	ThreatQ Object Type or Attribute Key	Published Date	Examples	Notes
.data[].	Onion	Onion	Current Timestamp	pedohub6lyqy7pla.onion	The .onion nodes are automatically added to ThreatQ and related to the primary object

Hashes (MD5, SHA-1, SHA-256)

GET https://api.aikostek.com/v2/lookup/hash

Sample Response:

{
  "data": [
    {
      "appearances": [
        "22kx7cbfnz6cwhz2.onion",
        "2464b3fu462tx2en.onion",
        "24mtxzx54uexcnrs.onion",
        "25ijhvugmashun4x.onion",
        "2ba4l7ihpln5krxs.onion",
        "2cj2kjlxtwbfytbl.onion",
        "2deogh434fawggi7.onion",
        "2dlp7y6hz7s43haz.onion",
        "2k62gpuyurilf5fh.onion",
        "2splewjorncdtgls.onion",
        "2yafdfcfigpj2kd2.onion",
        "2z2kekl4xsry4fvi.onion",
        "2zdche5xwicvayv6.onion",
        "2zmicnxnb5324msg.onion",
        "34ljepgdnctyqndm.onion",
        "zzdcf3fpnfcn7l24.onion",
        "vbj36rtt5sdomdi7f6gy4y3sjot3z5dcm3pkofv3bujwvc7qv5q6wbyd.onion",
        "joyaqqqf3cs4koe6siz5ab3xx36ukbfuxxuew7mil55zs5r7ndnvycqd.onion",
        "iqxkqwppsnbxcd4tj7vlhyspvz2oy4id6znfmhthaq7wphaakjasr3id.onion",
        "f6ha7dpjcyi3ohrd3o3fqxmkjdvmkp6uuyvetiqlgnzxoeekcqhdudyd.onion"
      ],
      "filename": "4.png",
      "first_seen": "2021-06-17T10:01:12Z",
      "md5": "ef212899150c852b6677a0b8bbf113f3",
      "onion": "22kx7cbfnz6cwhz2.onion",
      "sha1": "a96549dd6cee4630ef9763f2988c445a98b5778e",
      "sha256": "2b0d7124e05dba6b5d0de095ca09f0781213939be0dcda3bd66dec49cab4d1b3",
      "source_url": "hXXp://22kx7cbfnz6cwhz2[.]onion/",
      "url": "hXXp://22kx7cbfnz6cwhz2[.]onion/CHILDPORNCENTER/4.png"
    }
  ]
}

ThreatQuotient provides the following default mapping for this action:

Feed Data Path	ThreatQ Entity	ThreatQ Object Type or Attribute Key	Published Date	Examples	Notes
.data[].	Onion	Onion	Current Timestamp	2z2kekl4xsry4fvi.onion	The .onion nodes are automatically added to ThreatQ and related to the primary object
.data[].	Indicator	Filename	Current Timestamp	4.png
.data[].	Indicator	MD5	Current Timestamp	ef212899150c852b6677a 0b8bbf113f3
.data[].	Indicator	SHA-1	Current Timestamp	a96549dd6cee4630ef976 3f2988c445a98b5778e
.data[].	Indicator	SHA-256	Current Timestamp	2b0d7124e05dba6b5d0de 095ca09f0781213939be0d cda3bd66dec49cab4d1b3
.data[].	Indicator	URL	Current Timestamp	hXXp://22kx7cbfnz6cwhz2 [.]onion/CHILDPORNCENT ER/4.png

IP Address

GET https://api.aikostek.com/v2/lookup/ip

Sample Response:

{
  "data": [
    {
      "appearances": [
        "hpf2suizq5llpg6b.onion",
        "kzuywmbp5vsd6a3h.onion",
        "ovnhblrjrpf3x5k4.onion",
        "e5kornfjykwb7jif.onion",
        "tubeabf4racapudw.onion",
        "2ytx47bzuorew4id.onion",
        "vp4egeld5gh3wny3.onion",
        "e464ynqdbn3wdzhr.onion",
        "a64azcam7zdkug5u.onion",
        "lz7yglodon4s4kpy.onion",
        "3lmt2qhh3kct3ocy.onion",
        "zg43cdq7r36zgmlwqie5ijcwg7v6fhry2hvmokuyzn6h743jvwq34sid.onion",
        "4four5xmolkr2yqqgxkqv2dpks4cghafyked555si3aktzrfsnl5pcyd.onion",
        "ryeuyd3sqpqrfczicvej2dcluu2rcob55hivengfwdec3bvbron2l7id.onion",
        "ig6tu53xl5s7wmwzbi3uvdyq3vntlb6czbalskbfg6cot6ybvnyafhyd.onion"
      ],
      "meta": {
        "city": "Yonkers",
        "country": "US",
        "hostname": "ool-182f2e3f.dyn.optonline.net",
        "loc": "40.9312,-73.8988",
        "org": "AS6128 Cablevision Systems Corp.",
        "postal": "10702",
        "region": "New York",
        "timezone": "America/New_York"
      },
      "selector": "1.1.57.69",
      "source_url": [
        "http://dqcdd6m64tte2nt3v5xwkyadakhougkhnsqkmloh2cfy44ne7wty23yd.onion/login"
      ],
      "type": "ip"
    }
  ]
}

ThreatQuotient provides the following default mapping for this action:

Feed Data Path	ThreatQ Entity	ThreatQ Object Type or Attribute Key	Published Date	Examples	Notes
.data[].	Onion	Onion	Current Timestamp	a64azcam7zdkug5u.onion	The .onion nodes are automatically added to ThreatQ and related to the primary object
.data[].	indicator.attribute	City	Current Timestamp	Yonkers
.data[].	indicator.attribute	Country	Current Timestamp	US
.data[].	indicator.attribute	Region	Current Timestamp	New York
.data[].	indicator.attribute	Timezone	Current Timestamp	America/New_York
.data[].	indicator.attribute	Geolocation	Current Timestamp	40.9312,-73.8988
.data[].	indicator.attribute	Postal Code	Current Timestamp	10702
.data[].	indicator.attribute	Organization	Current Timestamp	AS6128 Cablevision Systems Corp.
.data[].	indicator.attribute	Hostname	Current Timestamp	ool-182f2e3f.dyn.optonline.net

Search Project Hades (Cryptocurrency)

High-level summary of what info the action does

GET https://api.aikostek.com/v2/lookup/crypto

Sample Response:

{
  "data": [
    {
      "appearances": [
        "bngoskfo32g3mjzo.onion",
        "jjlcfbdzivju5bh2.onion",
        "tzcrbsdfetmohmms.onion",
        "skcnr65vumlo6eaz.onion",
        "5th3cqxt4jqjepdm.onion",
        "wvzb5aqijvbe7t7w.onion",
        "dsnrhcttjax66jzf.onion",
        "tajcpga3m7okprcw.onion",
        "wiukcn7en7itzqvu.onion",
        "eongxahzuxsganqo.onion",
        "oaiavbaamzwmc7sp.onion",
        "lotto3gggtl3lnldipcb3co5bc3rbpfxebdcuf3dild7llxv3cg3gtid.onion",
        "3c2xastt7ripfjjyr3iaalu2rhjsnspwnbjma2sf23ob2rruz6eviiid.onion"
      ],
      "meta": "",
      "selector": "3JgfqZmwGFseH7hpkmrejyoryUkXaXriyE",
      "type": "bitcoin"
    }
  ]
}

ThreatQuotient provides the following default mapping for this action:

Feed Data Path	ThreatQ Entity	ThreatQ Object Type or Attribute Key	Published Date	Examples	Notes
.data[].	Onion	Onion	Current Timestamp	oaiavbaamzwmc7sp.onion	The .onion nodes are automatically added to ThreatQ and related to the primary object

PDF Guides

Document	ThreatQ Version
Project Hades Operation Guide v1.0.0	4.57.2 or Greater
