Censys Operation

The web format of this guide reflects the most current release.  Guides for older iterations are available in PDF format.

Integration Details

ThreatQuotient provides the following details for this integration:

Introduction

The Censys Operation enriches ThreatQ objects with context obtained from the Censys API.

The operation provides the following actions:

  • submit_ip - submits a selected IP Address for analysis.
  • submit_domain - submits a selected domain for analysis.
  • submit_hash - submits a selected hash for analysis.

The operation is compatible with the following indicator types:

  • FQDN
  • IP Address
  • SHA-256

Prerequisites

The following is required to run the integration:

  • A Censys API Key and API Secret

Installation

Perform the following steps to install the integration:

The same steps can be used to upgrade the integration to a new version.

  1. Log into https://marketplace.threatq.com/.
  2. Locate and download the integration file.
  3. Navigate to the integrations management page on your ThreatQ instance.
  4. Click on the Add New Integration button.
  5. Upload the integration file using one of the following methods:
    • Drag and drop the file into the dialog box
    • Select Click to Browse to locate the integration file on your local machine

    ThreatQ will inform you if the operation already exists on the platform and will require user confirmation before proceeding. ThreatQ will also inform you if the new version of the operation contains changes to the user configuration. The new user configurations will overwrite the existing ones for the operation and will require user confirmation before proceeding.

The operation is now installed and will be displayed in the ThreatQ UI. You will still need to configure and then enable the operation.

Configuration

ThreatQuotient does not issue API keys for third-party vendors. Contact the specific vendor to obtain API keys and other integration-related credentials.

To configure the integration:

  1. Navigate to your integrations management page in ThreatQ.
  2. Select the Operation option from the Type dropdown (optional).
  3. Click on the integration entry to open its details page.
  4. Enter the following parameters under the Configuration tab:
    Parameter Description
    API Key Enter your Censys API key.
    API Secret Enter your Censys API Secret.
  5. Review any additional settings, make any changes if needed, and click on Save.
  6. Click on the toggle switch, located above the Additional Information section, to enable it.

Actions

The operation provides the following actions:

Action Description Object Type Object Subtype
submit_ip Submits IP for analysis. Indicator IP
submit_domain Submits domain for analysis. Indicator FQDN
submit_hash Submits hash for analysis. Indicator SHA-256

submit_ip

The submit_ip action submits an ip address for analysis.

GET https://search.censys.io/api/v2/hosts/{{}}

Sample Response:

{
    "code": 200,
    "status": "OK",
    "result": {
        "ip": "194.28.226.169",
        "services": [
            {
                "_decoded": "ftp",
                "_encoding": {
                    "banner": "DISPLAY_UTF8",
                    "banner_hex": "DISPLAY_HEX"
                },
                "banner": "220 (vsFTPd 3.0.2)\r\n",
                "banner_hashes": [
                    "sha256:be807b6c864510e24fcd790176022670a059784cdb11dbad8edca428037bcabb"
                ],
                "banner_hex": "323230202876734654506420332e302e32290d0a",
                "discovery_method": "IPV4_WALK_FULL_PRIORITY_1",
                "extended_service_name": "FTP",
                "ftp": {
                    "_encoding": {
                        "banner": "DISPLAY_UTF8",
                        "auth_tls_response": "DISPLAY_UTF8",
                        "auth_ssl_response": "DISPLAY_UTF8"
                    },
                    "banner": "220 (vsFTPd 3.0.2)\r\n",
                    "auth_tls_response": "530 Please login with USER and PASS.\r\n",
                    "auth_ssl_response": "530 Please login with USER and PASS.\r\n",
                    "status_code": 220,
                    "status_meaning": "Service ready for new user.",
                    "implicit_tls": false
                },
                "labels": [
                    "file-sharing"
                ],
                "observed_at": "2023-08-21T02:24:56.795849172Z",
                "perspective_id": "PERSPECTIVE_TATA",
                "port": 21,
                "service_name": "FTP",
                "software": [
                    {
                        "uniform_resource_identifier": "cpe:2.3:a:vsftpd_project:vsftpd:3.0.2:*:*:*:*:*:*:*",
                        "part": "a",
                        "vendor": "vsFTPd Project",
                        "product": "vsFTPd",
                        "version": "3.0.2",
                        "other": {
                            "family": "vsFTPd"
                        },
                        "source": "OSI_APPLICATION_LAYER"
                    }
                ],
                "source_ip": "167.94.138.36",
                "transport_fingerprint": {
                    "raw": "28960,64,true,MSTNW,1408,false,false"
                },
                "transport_protocol": "TCP",
                "truncated": false
            }
        ],
        "location": {
            "continent": "Europe",
            "country": "Germany",
            "country_code": "DE",
            "city": "Frankfurt am Main",
            "postal_code": "60313",
            "timezone": "Europe/Berlin",
            "province": "Hesse",
            "coordinates": {
                "latitude": 50.1153,
                "longitude": 8.6823
            }
        },
        "location_updated_at": "2023-08-20T00:09:53.056505Z",
        "autonomous_system": {
            "asn": 201671,
            "description": "AS-NUXTCLOUD",
            "bgp_prefix": "194.28.226.0/24",
            "name": "AS-NUXTCLOUD",
            "country_code": "GB"
        },
        "autonomous_system_updated_at": "2023-08-20T00:09:53.056626Z",
        "operating_system": {
            "uniform_resource_identifier": "cpe:2.3:o:redhat:enterprise_linux:7:*:*:*:*:*:*:*",
            "part": "o",
            "vendor": "Red Hat",
            "product": "Enterprise Linux",
            "version": "7",
            "other": {
                "family": "Linux"
            }
        },
        "dns": {
            "reverse_dns": {
                "names": [
                    "google.com"
                ],
                "resolved_at": "2023-08-19T11:46:51.655505631Z"
            }
        },
        "last_updated_at": "2023-08-22T03:44:55.321Z",
        "labels": [
            "remote-access",
            "email",
            "file-sharing"
        ]
    }
}

ThreatQ provides the following default mapping for this operation action:

Provider Data Path ThreatQ Entity ThreatQ Object Type or Attribute Key Examples Notes
.result.autonomous_system.country_code Indicator.Attribute Network Country Code GB N/A
.result.autonomous_system.name Indicator.Attribute Network AS-NUXTCLOUD N/A
.result.autonomous_system.bgp_prefix Indicator.Attribute BGP Prefix 194.28.226.0/24 N/A
.result.autonomous_system.description Indicator.Attribute Description AS-NUXTCLOUD N/A
.result.autonomous_system.asn Indicator.Attribute ASN 201671 N/A
.result.location.postal_code Indicator.Attribute Postal Code 60313 N/A
.result.location.timezone Indicator.Attribute Timezone Europe/Berlin N/A
.result.location.province Indicator.Attribute Province Hesse N/A
.result.location.country_code Indicator.Attribute Country Code DE N/A
.result.location.continent Indicator.Attribute Continent Europe N/A
.result.location.city Indicator.Attribute City Frankfurt am Main N/A
.result.location.country Indicator.Attribute Country Germany N/A
.result.dns.names Related Indicator.Value FQDN google.com N/A
.result.dns.reverse_dns.names Related Indicator.Value FQDN google.com N/A
.result.services.tls.certificates.leaf_data.names Related Indicator.Value FQDN google.com Values validated as FQDN. Entries that are IP literals are converted to IP Address/IPv6 Address indicators automatically.
.result.services.banner_hashes Related Indicator.Value SHA-256/MD5/SHA-1/Hash ION 446a6087825fa73eadb045e5a2e9e2adf7df241b571228187728191d961dda1f See the Hash Logic Mapping Table.
.result.services.http.response.body_hashes Related Indicator.Value SHA-256/MD5/SHA-1/Hash ION 446a6087825fa73eadb045e5a2e9e2adf7df241b571228187728191d961dda1f See the Hash Logic Mapping Table.
.result.services.http.response.favicons.hashes Related Indicator.Value SHA-256/MD5/SHA-1/Hash ION 446a6087825fa73eadb045e5a2e9e2adf7df241b571228187728191d961dda1f See the Hash Logic Mapping Table.
.result.operating_system.vendor Indicator.Attribute Vendor Red Hat N/A
.result.operating_system.product Indicator.Attribute Product Enterprise Linux N/A
.result.operating_system.uniform_resource_identifier Indicator.Attribute CPE cpe:2.3:o:redhat:enterprise_linux:7:*:*:*:*:*:*:* N/A
.result.labels Indicator.Attribute Tag email N/A
.result.services.labels Indicator.Attribute Tag remote-access N/A
.result.services.jarm.fingerprint Related Fingerprint Indicator.Value Hash ION 27d27d27d00027d00042d43d00041df04c41293ba84f6efe3a613b22f983e6 N/A
.result.services.tls.ja3s Related Fingerprint Indicator.Value Hash ION d75f9129bb5d05492a65ff78e081bcb2 N/A
.result.services.tls.ja4s Related Fingerprint Indicator.Value Hash ION t130200_1303_234ea6891581 N/A

Hash Logic Mapping Table

The following tables illustrates hash mapping logic from Censys to ThreatQ.

Prefix Target Indicator Type Example
md5 MD5 49532cbc459e8e7ceb1249f5fdbab31c
sha1 SHA-1 7436e0b4b1f8c222c38069890b75fa2baf9ca620
sha256 SHA-256 9a2e3208b3b63b0f17c1e901a31bb8f1efa50fb21e5260583af2f6e9e4ef9ba8
phash Hash ION 904e5baf3b54324b
tlsh Hash ION 46a2623386099470ad747eafcba7750d80f8f19288c357c4e4ad0d65dd6ef0a3a5b298

submit_domain

The submit_domain action submits a selected domain for analysis.

GET https://search.censys.io/api/v2/hosts/search?q={{domain}}

Sample Response:

{
    "code": 200,
    "status": "OK",
    "result": {
        "query": "google.com",
        "total": 1055920,
        "duration": 629,
        "hits": [
            {
                "autonomous_system": {
                    "country_code": "RU",
                    "name": "SPACENET-AS Internet Service Provider",
                    "description": "SPACENET-AS Internet Service Provider",
                    "bgp_prefix": "62.173.128.0/19",
                    "asn": 34300
                },
                "last_updated_at": "2023-08-21T05:32:23.796Z",
                "location": {
                    "postal_code": "101000",
                    "timezone": "Europe/Moscow",
                    "province": "Moscow",
                    "country_code": "RU",
                    "continent": "Europe",
                    "city": "Moscow",
                    "coordinates": {
                        "latitude": 55.75222,
                        "longitude": 37.61556
                    },
                    "country": "Russia"
                },
                "ip": "62.173.142.225",
                "operating_system": {
                    "component_uniform_resource_identifiers": [],
                    "source": "OSI_TRANSPORT_LAYER",
                    "other": [],
                    "part": "o",
                    "product": "linux",
                    "cpe": "cpe:2.3:o:*:linux:*:*:*:*:*:*:*:*"
                },
                "services": [
                    {
                        "service_name": "FTP",
                        "transport_protocol": "TCP",
                        "port": 21,
                        "extended_service_name": "FTP"
                    },
                    {
                        "transport_protocol": "TCP",
                        "port": 22,
                        "extended_service_name": "SSH",
                        "service_name": "SSH"
                    },
                    {
                        "certificate": "26e97467fb89414a31953aa89f207f602b5d1acfdd939236b87b977b05029097",
                        "port": 25,
                        "extended_service_name": "SMTP-STARTTLS",
                        "transport_protocol": "TCP",
                        "service_name": "SMTP"
                    },
                    {
                        "service_name": "DNS",
                        "port": 53,
                        "transport_protocol": "UDP",
                        "extended_service_name": "DNS"
                    },
                    {
                        "port": 80,
                        "transport_protocol": "TCP",
                        "extended_service_name": "HTTP",
                        "service_name": "HTTP"
                    },
                    {
                        "extended_service_name": "POP3",
                        "port": 110,
                        "transport_protocol": "TCP",
                        "service_name": "POP3"
                    },
                    {
                        "transport_protocol": "TCP",
                        "extended_service_name": "IMAP",
                        "service_name": "IMAP",
                        "port": 143
                    },
                    {
                        "certificate": "0da9ea92b7a8f30a79e3c59effda579a9a016455c7e24f6db46419a0b117b6c8",
                        "transport_protocol": "TCP",
                        "extended_service_name": "SMTP-STARTTLS",
                        "service_name": "SMTP",
                        "port": 587
                    },
                    {
                        "extended_service_name": "UNKNOWN",
                        "service_name": "UNKNOWN",
                        "transport_protocol": "TCP",
                        "port": 8243
                    },
                    {
                        "transport_protocol": "TCP",
                        "extended_service_name": "HTTP",
                        "port": 9189,
                        "service_name": "HTTP"
                    }
                ],
                "dns": {
                    "reverse_dns": {
                        "names": [
                            "google.com"
                        ]
                    }
                }
            }
          ]
    }
}

ThreatQ provides the following default mapping for this operation action:

Provider Data Path ThreatQ Entity ThreatQ Object Type or Attribute Key Examples Notes
.result.hits[].autonomous_system.country_code Indicator.Attribute Network Country Code RU N/A
.result.hits[].autonomous_system.name Indicator.Attribute Network SPACENET-AS Internet Service Provider N/A
.result.hits[].autonomous_system.bgp_prefix Indicator.Attribute BGP Prefix 62.173.128.0/19 N/A
.result.hits[].autonomous_system.description Indicator.Attribute Description SPACENET-AS Internet Service Provider N/A
.result.hits[].autonomous_system.asn Indicator.Attribute ASN 34300 N/A
.result.hits[].location.postal_code Indicator.Attribute Postal Code 101000 N/A
.result.hits[].location.timezone Indicator.Attribute Timezone Europe/Moscow N/A
.result.hits[].location.province Indicator.Attribute Province Moscow N/A
.result.hits[].location.country_code Indicator.Attribute Country Code RU N/A
.result.hits[].location.continent Indicator.Attribute Continent Europe N/A
.result.hits[].location.city Indicator.Attribute City Moscow N/A
.result.hits[].location.country Indicator.Attribute Country Russia N/A
.result.hits[].ip Related Indicator.Value IP Address/ IPv6 Address 62.173.142.225 N/A
.result.hits[].operating_system.source Indicator.Attribute Source OSI_TRANSPORT_LAYER N/A
.result.hits[].operating_system.product Indicator.Attribute Product linux N/A
.result.hits[].operating_system.cpe Indicator.Attribute CPE cpe:2.3:o:*:linux:*:*:*:*:*:*:*:* N/A

submit_hash

The submit_hash submits the selected hash for analysis.

GET https://search.censys.io/api/v2/certificates/{{hash}}

Sample Response:

{
    "code": 200,
    "status": "OK",
    "result": {
        "_encoding": {
            "fingerprint_sha256": "DISPLAY_HEX",
            "fingerprint_sha1": "DISPLAY_HEX",
            "fingerprint_md5": "DISPLAY_HEX",
            "tbs_fingerprint_sha256": "DISPLAY_HEX",
            "tbs_no_ct_fingerprint_sha256": "DISPLAY_HEX",
            "spki_fingerprint_sha256": "DISPLAY_HEX",
            "parent_spki_fingerprint_sha256": "DISPLAY_HEX",
            "raw": "DISPLAY_BASE64",
            "spki_subject_fingerprint_sha256": "DISPLAY_HEX",
            "parent_spki_subject_fingerprint_sha256": "DISPLAY_HEX"
        },
        "fingerprint_sha256": "9b00121b4e85d50667ded1a8aa39855771bdb67ceca6f18726b49374b41f0041",
        "fingerprint_sha1": "d508e7f8163fb67434f84091dc7c2ca8afd5234d",
        "fingerprint_md5": "3818d99263b47ab28f7de5b293ee1418",
        "tbs_fingerprint_sha256": "4b098b6bd9459340fb0f3cfb80f0bc3283370c455d57ca20da40e7eecce341d5",
        "tbs_no_ct_fingerprint_sha256": "5c095a40e76c245323086d26d1fa428d3b443b42fb58c7dbb19b32dfe516b749",
        "spki_fingerprint_sha256": "cc9b074ebf41b484a56923d5585594967bda7a7f8b5be187ef0e7ae1ec90003c",
        "parent_spki_fingerprint_sha256": "390bc358202771a65e7be7a87924d7f2a079de04feb5ffd4163fae4fbf9b11e9",
        "parsed": {
            "version": 3,
            "serial_number": "311703586789118042424998420179537559397550",
            "issuer_dn": "C=US, O=Let's Encrypt, CN=R3",
            "issuer": {
                "common_name": [
                    "R3"
                ],
                "country": [
                    "US"
                ],
                "organization": [
                    "Let's Encrypt"
                ]
            },
            "subject_dn": "CN=www.kgcontracting.co",
            "subject": {
                "common_name": [
                    "www.kgcontracting.co"
                ]
            },
            "subject_key_info": {
                "key_algorithm": {
                    "name": "RSA",
                    "oid": "1.2.840.113549.1.1.1"
                },
                "rsa": {
                    "exponent": 65537,
                    "_encoding": {
                        "modulus": "DISPLAY_HEX"
                    },
                    "modulus": "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",
                    "length": 2048
                },
                "_encoding": {
                    "fingerprint_sha256": "DISPLAY_HEX"
                },
                "fingerprint_sha256": "754cb1e2e2088214a5970662bb5a60aec8a2e29b94f53529aa608abee6682c60",
                "_key": "rsa"
            },
            "validity_period": {
                "not_before": "2022-12-31T11:37:55Z",
                "not_after": "2023-03-31T11:37:54Z",
                "length_seconds": 7775999
            },
            "signature": {
                "signature_algorithm": {
                    "name": "SHA256-RSA",
                    "oid": "1.2.840.113549.1.1.11"
                },
                "_encoding": {
                    "value": "DISPLAY_HEX"
                },
                "value": "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",
                "valid": true,
                "self_signed": false
            },
            "extensions": {
                "key_usage": {
                    "digital_signature": true,
                    "key_encipherment": true,
                    "value": 5,
                    "content_commitment": false,
                    "data_encipherment": false,
                    "key_agreement": false,
                    "certificate_sign": false,
                    "crl_sign": false,
                    "encipher_only": false,
                    "decipher_only": false
                },
                "basic_constraints": {
                    "is_ca": false
                },
                "subject_alt_name": {
                    "dns_names": [
                        "kgcontracting.co",
                        "www.kgcontracting.co"
                    ]
                },
                "_encoding": {
                    "authority_key_id": "DISPLAY_HEX",
                    "subject_key_id": "DISPLAY_HEX"
                },
                "authority_key_id": "142eb317b75856cbae500940e61faf9d8b14c2c6",
                "subject_key_id": "a6a1b9ac9d0886b3b58f5faba9f42f741d9ef29d",
                "extended_key_usage": {
                    "server_auth": true,
                    "client_auth": true,
                    "apple_code_signing": false,
                    "apple_code_signing_development": false,
                    "apple_software_update_signing": false,
                    "apple_code_signing_third_party": false,
                    "apple_resource_signing": false,
                    "apple_ichat_signing": false,
                    "apple_ichat_encryption": false,
                    "apple_system_identity": false,
                    "apple_crypto_env": false,
                    "apple_crypto_production_env": false,
                    "apple_crypto_maintenance_env": false,
                    "apple_crypto_test_env": false,
                    "apple_crypto_development_env": false,
                    "apple_crypto_qos": false,
                    "apple_crypto_tier0_qos": false,
                    "apple_crypto_tier1_qos": false,
                    "apple_crypto_tier2_qos": false,
                    "apple_crypto_tier3_qos": false,
                    "microsoft_cert_trust_list_signing": false,
                    "microsoft_qualified_subordinate": false,
                    "microsoft_key_recovery_3": false,
                    "microsoft_document_signing": false,
                    "microsoft_lifetime_signing": false,
                    "microsoft_mobile_device_software": false,
                    "microsoft_smart_display": false,
                    "microsoft_csp_signature": false,
                    "microsoft_timestamp_signing": false,
                    "microsoft_server_gated_crypto": false,
                    "microsoft_sgc_serialized": false,
                    "microsoft_encrypted_file_system": false,
                    "microsoft_efs_recovery": false,
                    "microsoft_whql_crypto": false,
                    "microsoft_nt5_crypto": false,
                    "microsoft_oem_whql_crypto": false,
                    "microsoft_embedded_nt_crypto": false,
                    "microsoft_root_list_signer": false,
                    "microsoft_drm": false,
                    "microsoft_drm_individualization": false,
                    "microsoft_licenses": false,
                    "microsoft_license_server": false,
                    "microsoft_enrollment_agent": false,
                    "microsoft_smartcard_logon": false,
                    "microsoft_ca_exchange": false,
                    "microsoft_key_recovery_21": false,
                    "microsoft_system_health": false,
                    "microsoft_system_health_loophole": false,
                    "microsoft_kernel_mode_code_signing": false,
                    "dvcs": false,
                    "sbgp_cert_aa_service_auth": false,
                    "eap_over_ppp": false,
                    "eap_over_lan": false,
                    "code_signing": false,
                    "email_protection": false,
                    "ipsec_end_system": false,
                    "ipsec_tunnel": false,
                    "ipsec_user": false,
                    "time_stamping": false,
                    "ocsp_signing": false,
                    "ipsec_intermediate_system_usage": false,
                    "netscape_server_gated_crypto": false,
                    "any": false
                },
                "certificate_policies": [
                    {
                        "id": "2.23.140.1.2.1"
                    },
                    {
                        "id": "1.3.6.1.4.1.44947.1.1.1",
                        "cps": [
                            "http://cps.letsencrypt.org"
                        ]
                    }
                ],
                "authority_info_access": {
                    "ocsp_urls": [
                        "http://r3.o.lencr.org"
                    ],
                    "issuer_urls": [
                        "http://r3.i.lencr.org/"
                    ]
                },
                "signed_certificate_timestamps": [
                    {
                        "_encoding": {
                            "log_id": "DISPLAY_HEX"
                        },
                        "log_id": "b73efb24df9c4dba75f239c5ba58f46c5dfc42cf7a9f35c49e1d098125edb499",
                        "timestamp": "2022-12-31T12:37:55Z",
                        "signature": {
                            "hash_algorithm": "SHA256",
                            "signature_algorithm": "ECDSA",
                            "_encoding": {
                                "signature": "DISPLAY_HEX"
                            },
                            "signature": "304402203e73c9d1e7f17087b077237c715039e1d5f36cd75635df44017767227354dd7d022017cfb6779130c48b496851d5aeb970c3b43e0fa1f31d6bc03f3338d7b8716947"
                        },
                        "version": 0
                    },
                    {
                        "_encoding": {
                            "log_id": "DISPLAY_HEX"
                        },
                        "log_id": "e83ed0da3ef5063532e75728bc896bc903d3cbd1116beceb69e1777d6d06bd6e",
                        "timestamp": "2022-12-31T12:37:55Z",
                        "signature": {
                            "hash_algorithm": "SHA256",
                            "signature_algorithm": "ECDSA",
                            "_encoding": {
                                "signature": "DISPLAY_HEX"
                            },
                            "signature": "30450221009c728da43c9bf4700b6d73c3b3155b5473d629d5b8f06c7335894ce61fbf3af002202e677d64f8e7368e39769ba45812fa3d0a2e3cce761d8e898276392d592b5475"
                        },
                        "version": 0
                    }
                ],
                "ct_poison": false
            },
            "serial_number_hex": "039403b7283199171fd9c1af1c8210f5a4ae",
            "redacted": false
        },
        "names": [
            "kgcontracting.co",
            "www.kgcontracting.co"
        ],
        "validation_level": "DV",
        "validation": {
            "nss": {
                "ever_valid": true,
                "had_trusted_path": true,
                "chains": [
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    },
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    }
                ],
                "_encoding": {
                    "parents": "DISPLAY_HEX"
                },
                "parents": [
                    "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                    "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd"
                ],
                "type": "LEAF",
                "is_valid": false,
                "has_trusted_path": false,
                "in_revocation_set": false
            },
            "microsoft": {
                "ever_valid": true,
                "had_trusted_path": true,
                "chains": [
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    },
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    }
                ],
                "_encoding": {
                    "parents": "DISPLAY_HEX"
                },
                "parents": [
                    "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                    "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd"
                ],
                "type": "LEAF",
                "is_valid": false,
                "has_trusted_path": false,
                "in_revocation_set": false
            },
            "apple": {
                "ever_valid": true,
                "had_trusted_path": true,
                "chains": [
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    },
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    }
                ],
                "_encoding": {
                    "parents": "DISPLAY_HEX"
                },
                "parents": [
                    "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                    "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd"
                ],
                "type": "LEAF",
                "is_valid": false,
                "has_trusted_path": false,
                "in_revocation_set": false
            },
            "chrome": {
                "ever_valid": true,
                "had_trusted_path": true,
                "chains": [
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    },
                    {
                        "_encoding": {
                            "sha256fp": "DISPLAY_HEX"
                        },
                        "sha256fp": [
                            "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd",
                            "96bcec06264976f37460779acf28c5a7cfe8a3c0aae11a8ffcee05c0bddf08c6"
                        ]
                    }
                ],
                "_encoding": {
                    "parents": "DISPLAY_HEX"
                },
                "parents": [
                    "0ac730f6b3a98bab6aa97c9c4c71b34dd5599f4933630e6d24a26751bd12ebac",
                    "67add1166b020ae61b8f5fc96813c04c2aa589960796865572a3c7e737613dfd"
                ],
                "type": "LEAF",
                "is_valid": false,
                "has_trusted_path": false,
                "in_revocation_set": false
            }
        },
        "ct": {
            "entries": {
                "google_xenon_2023": {
                    "index": 593655844,
                    "added_to_ct_at": "2022-12-31T12:37:55.906Z",
                    "ct_to_censys_at": "2023-06-21T10:02:57.281327695Z"
                },
                "google_argon_2023": {
                    "index": 521618614,
                    "added_to_ct_at": "2022-12-31T12:37:55.858Z",
                    "ct_to_censys_at": "2023-05-04T22:00:22.709312248Z"
                }
            }
        },
        "ever_seen_in_scan": true,
        "raw": "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",
        "added_at": "2023-01-06T12:46:27Z",
        "modified_at": "2023-06-21T10:02:57Z",
        "validated_at": "2023-06-10T05:12:10Z",
        "parse_status": "CERTIFICATE_PARSE_STATUS_SUCCESS",
        "zlint": {
            "version": 3,
            "timestamp": "2023-06-13T05:04:17Z",
            "notices_present": true,
            "failed_lints": [
                "n_subject_common_name_included"
            ],
            "warnings_present": false,
            "errors_present": false,
            "fatals_present": false
        },
        "spki_subject_fingerprint_sha256": "cc9b074ebf41b484a56923d5585594967bda7a7f8b5be187ef0e7ae1ec90003c",
        "parent_spki_subject_fingerprint_sha256": "390bc358202771a65e7be7a87924d7f2a079de04feb5ffd4163fae4fbf9b11e9",
        "precert": false,
        "revoked": false,
        "labels": [
            "leaf",
            "ct",
            "ever-trusted",
            "untrusted",
            "dv",
            "was-trusted",
            "expired",
            "google-ct"
        ]
    }
}

ThreatQ provides the following default mapping for this operation action:

Provider Data Path ThreatQ Entity ThreatQ Object Type or Attribute Key Examples Notes
.result.fingerprint_sha1 Related Indicator.Value SHA-1 d508e7f8163fb67434f84091dc7c2ca8afd5234d N/A
.result.fingerprint_md5 Related Indicator.Value MD5 3818d99263b47ab28f7de5b293ee1418 N/A
.result.tbs_fingerprint_sha256 Related Indicator.Value SHA-256 4b098b6bd9459340fb0f3cfb80f0bc3283370c455d57ca20da40e7eecce341d5 N/A
.result.tbs_no_ct_fingerprint_sha256 Related Indicator.Value SHA-256 5c095a40e76c245323086d26d1fa428d3b443b42fb58c7dbb19b32dfe516b749 N/A
.result.spki_fingerprint_sha256 Related Indicator.Value SHA-256 cc9b074ebf41b484a56923d5585594967bda7a7f8b5be187ef0e7ae1ec90003c N/A
.result.parent_spki_fingerprint_sha256 Related Indicator.Value SHA-256 390bc358202771a65e7be7a87924d7f2a079de04feb5ffd4163fae4fbf9b11e9 N/A
.result.parsed.issuer_dn Indicator.Attribute Issuer Distinguished Name C=US, O=Let's Encrypt, CN=R3 N/A
.result.parsed.serial_number Indicator.Attribute Serial Number 311703586789118042424998420179537559397550 N/A
.result.parsed.signature.self_signed Indicator.Attribute Self Signed False N/A
.result.parsed.signature.valid Indicator.Attribute Valid Signature True N/A
.result.parsed.signature.signature_algorithm.name Indicator.Attribute Signature Algorithm Name SHA256-RSA N/A
.result.parsed.signature.signature_algorithm.oid Indicator.Attribute Signature Algorithm OID 1.2.840.113549.1.1.11 N/A
.result.parsed.signature.value Indicator.Attribute Signature 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 N/A
.result.parsed.extensions.subject_alt_name.dns_names Indicator.Attribute DNS Names kgcontracting.co N/A
.result.validation.apple.had_trusted_path Indicator.Attribute Browser Trust Apple True N/A
.result.validation.microsoft.had_trusted_path Indicator.Attribute Browser Trust Microsoft True N/A
.result.validation.nss.had_trusted_path Indicator.Attribute Browser Trust Mozilla NSS True N/A
.result.validation.chrome.had_trusted_path Indicator.Attribute Browser Trust Chrome True N/A
.result.labels Indicator.Attribute Tag leaf N/A
.result.parsed.subject.common_name Indicator.Attribute Common Name www.kgcontracting.co N/A
.result.parsed.subject_key_info.key_algorithm.name Indicator.Attribute Key Type RSA N/A
.result.parsed.subject_key_info.rsa.length Indicator.Attribute Key Length 2048 N/A
.result.parsed.subject_key_info.rsa.modulus Indicator.Attribute Modulus 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 N/A
.result.parsed.extensions.key_usage.key_encipherment Indicator.Attribute Key Encipherment True N/A
.result.parsed.extensions.key_usage.digital_signature Indicator.Attribute Digital Signature True N/A
.result.parsed.extensions.extended_key_usage.server_auth Indicator.Attribute Server Auth True N/A
.result.parsed.extensions.extended_key_usage.client_auth Indicator.Attribute Client Auth True N/A
.result.parsed.extensions.basic_constraints.is_ca Indicator.Attribute Constraints False N/A
.result.parsed.extensions.authority_info_access.ocsp_urls Indicator.Attribute AIA Paths OCSP http://r3.i.lencr.org/ N/A
.result.parsed.extensions.authority_info_access.issuer_urls Indicator.Attribute AIA Paths Issuer http://r3.o.lencr.org N/A
.result.ct.entries.google_argon_2023.index Indicator.Attribute Certificate Transparency Argon 521618614 N/A
.result.ct.entries.google_argon_2023.added_to_ct_at Indicator.Attribute Certificate Transparency Argon Date 2022-12-31T12:37:55.858Z N/A
.result.ct.entries.google_xenon_2023.index Indicator.Attribute Certificate Transparency Xenon 593655844 N/A
.result.ct.entries.google_xenon_2023.added_to_ct_at Indicator.Attribute Certificate Transparency Xenon Date 2022-12-31T12:37:55.906Z N/A

Change Log

  • Version 1.2.0
    • Service labels are now mapped to Tag attributes. Banner data is preserved, and banner, body, and favicon hashes are normalized and ingested as related indicators, ensuring these fields are consistently captured.
    • DNS and FQDN coverage has been enhanced. Both forward (dns.names) and reverse DNS records are now ingested as related FQDN indicators, ensuring all hostnames associated with an IP address—including those previously omitted—are returned.
    • A new fingerprint section has been introduced to surface service JARM fingerprints and TLS JA3S/JA4S values, which are ingested as Hash ION indicators with the corresponding fingerprint type.
    • The minimum supported ThreatQ version has been updated to 5.15.0.
  • Version 1.1.0
    • Updated the API version and endpoints utilized by the operation.
      • Updated the ingested data samples and mapping tables.
  • Version 1.0.0
    • Initial release

PDF Guides

Document ThreatQ Version
Censys Operation Guide v1.2.0 5.15.0 or Greater
Censys Operation Guide v1.1.0 4.34.0 or Greater
Censys Operation Guide v1.0.0 4.34.0 or Greater
