Infoblox SOC Insights CDF

The web format of this guide reflects the most current release.  Guides for older iterations are available in PDF format.

Infoblox SOC Insights

The Infoblox SOC Insights retrieves the ID of an incident based on the user's configuration settings.

GET https://csp.infoblox.com/api/v1/insights

Sample Response:

{
   "insightList":[
      {
         "tClass":"TI-CONFIGURATIONISSUE",
         "tFamily":"OPENRESOLVER",
         "insightId":"ae414970-8878-42f5-9192-6c3319254b3a",
         "feedSource":"Insight Detection Framework",
         "startedAt":"2024-03-27T23:00:00Z",
         "threatType":"Open Resolver",
         "status":"Active",
         "persistentDate":"2024-03-27T15:00:00Z",
         "numEvents":"1472",
         "mostRecentAt":"2024-05-02T11:42:06Z",
         "eventsNotBlockedCount":"1472",
         "dateChanged":"0001-01-01T00:00:00Z",
         "priorityText":"MEDIUM"
      }
   ]
}

ThreatQ provides the following default mapping for this feed:

Feed Data Path	ThreatQ Entity	ThreatQ Object Type or Attribute Key	Published Date	Examples	Notes
insightList[].feedSource + insightList[].insightId	Incident.Value	N/A	insightList[].startedAt	Insight Detection Framework - ae414970-8878-42f5- 9192-6c3319254b3a	We concatenate the 2 values so the Incident value is unique
insightList[].priorityText	Incident.Attribute	Priority	insightList[].startedAt	MEDIUM	Attribute updated if already exists
insightList[].status	Incident.Attribute	Status	insightList[].startedAt	Active	Attribute updated if already exists
insightList[].threatType	Incident.Attribute	Threat Type	insightList[].startedAt	Open Resolver	N/A
insightList[].feedSource	Incident.Attribute	Feed Source	insightList[].startedAt	Insight Detection Framework	N/A
insightList[].tFamily	Incident.Attribute	Family	insightList[].startedAt	OPENRESOLVER	N/A
insightList[].tClass	Incident.Attribute	Class	insightList[].startedAt	TI-CONFIGURATIONISSUE	N/A
indicators[].indicator	Related Indicator.Value	FQDN	indicators[].timeMin	shadowserver.org	N/A
indicators[].confidence	Related Indicator.Attribute	Confidence Level	indicators[].timeMin	3	Attribute updated if already exists
indicators[].threatLevelMax	Related Indicator.Attribute	Threat Level Max	indicators[].timeMin	1	Attribute updated if already exists
indicators[].action	Related Indicator.Attribute	Action	indicators[].timeMin	Not Blocked	N/A
assets[].qip	Related Asset.Value	N/A	assets[].timeMin	107.178.234.206	N/A
assets[].threatIndicatorDistinctCount	Related Asset.Attribute	Threat Indicator Distinct Count	assets[].timeMin	1	Attribute updated if already exists
assets[].threatLevelMax	Related Asset.Attribute	Threat Level Max	assets[].timeMin	2	Attribute updated if already exists
events[].class + events[].threatFamily + events[].property	Related Event.Value	Incident	events[].detected	TI-CONFIGURATIONISSUE - OPENRESOLVER - dnsscan.shadowserver.org	We concatenate the 3 values so we can create the event
events[].confidenceLevel	Related Event.Attribute	Confidence Level	events[].detected	High	Attribute updated if already exists
events[].action	Related Event.Attribute	Action	events[].detected	Allow - No Log	N/A
events[].policy	Related Event.Attribute	Policy	events[].detected	DoH	N/A
events[].class	Related Event.Attribute	Class	events[].detected	TI-CONFIGURATIONISSUE	N/A
events[].threatFamily	Related Event.Attribute	Threat Family	events[].detected	OPENRESOLVER	N/A
events[].threatLevel	Related Event.Attribute	Threat Level	events[].detected	Low	Attribute updated if already exists
events[].deviceIp	Related Event.Indicator	IP Address	events[].detected	107.178.235.14	N/A

Get Indicators (Supplemental)

The Get Indicators supplemental feed retrieves all the indicators for each Incident.

GET https://csp.infoblox.com/api/v1/insights/{{insightId}}/indicators

Sample Response:

{
    "indicators": [
        {
            "action": "Not Blocked",
            "confidence": "3",
            "count": 703,
            "threatLevelMax": "1",
            "indicator": "shadowserver.org",
            "timeMax": "2024-05-02T11:00:00.000",
            "timeMin": "2024-04-02T13:00:00.000"
        },
        {
            "action": "Not Blocked",
            "confidence": "3",
            "count": 980,
            "threatLevelMax": "1",
            "indicator": "parrotdns.com",
            "timeMax": "2024-04-29T11:00:00.000",
            "timeMin": "2024-04-02T13:00:00.000"
        }
    ]
}

Get Assets (Supplemental)

The Get Assets supplemental feed retrieves all the assets for each Incident.

GET https://csp.infoblox.com/api/v1/insights/{{insightId}}/assets

Sample Response:

{
    "assets": [
        {
            "count": 355,
            "qip": "107.178.234.206",
            "threatLevelMax": "2",
            "threatIndicatorDistinctCount": "1",
            "timeMax": "2024-05-01T23:00:00.000",
            "timeMin": "2024-05-01T23:00:00.000"
        },
        {
            "count": 500,
            "qip": "107.178.234.197",
            "threatLevelMax": "2",
            "threatIndicatorDistinctCount": "2",
            "timeMax": "2024-05-01T15:00:00.000",
            "timeMin": "2024-05-01T15:00:00.000"
        },
        {
            "count": 765,
            "qip": "107.178.235.12",
            "threatLevelMax": "2",
            "threatIndicatorDistinctCount": "2",
            "timeMax": "2024-05-01T15:00:00.000",
            "timeMin": "2024-05-01T15:00:00.000"
        },
        {
            "count": 865921,
            "qip": "42.42.42.2",
            "threatLevelMax": "2",
            "threatIndicatorDistinctCount": "163",
            "timeMax": "2024-04-29T12:00:00.000",
            "timeMin": "2024-04-02T10:00:00.000"
        }
    ]
}

Get Events (Supplemental)

The Get Events supplemental feed retrieves all the events for each Incident.

GET https://csp.infoblox.com/api/v1/insights/{{insightId}}/events

Sample Response:

{
    "events": [
        {
            "confidenceLevel": "High",
            "source": "unknown",
            "action": "Allow - No Log",
            "policy": "DoH",
            "deviceIp": "107.178.235.14",
            "query": "dnsscan.shadowserver.org",
            "queryType": "A",
            "class": "TI-CONFIGURATIONISSUE",
            "threatFamily": "OPENRESOLVER",
            "detected": "2024-05-02 11:42:06 +0000 UTC",
            "property": "dnsscan.shadowserver.org",
            "user": "unknown",
            "threatLevel": "Low"
        },
        {
            "confidenceLevel": "High",
            "source": "unknown",
            "action": "Allow - No Log",
            "policy": "DoH",
            "deviceIp": "107.178.234.206",
            "query": "dnsscan.shadowserver.org",
            "queryType": "A",
            "class": "TI-CONFIGURATIONISSUE",
            "threatFamily": "OPENRESOLVER",
            "detected": "2024-05-01 23:42:09 +0000 UTC",
            "property": "dnsscan.shadowserver.org",
            "user": "unknown",
            "threatLevel": "Low"
        }
    ]
}

PDF Guides

Document	ThreatQ Version
Infoblox SOC Insights CDF Guide v1.1.0	5.22.0 or Greater
Infoblox Insights CDF Guide v1.0.0	5.22.0 or Greater
