TeamT5 ThreatVision Operation

The web format of this guide reflects the most current release.  Guides for older iterations are available in PDF format.

Enrich

The Enrich action enriches an IOC with context from ThreatVision. Network IOCs will be enriched using the ITM module's API, and sample IOCs will be enriched using the sample information API.

Sample IOCs (MD5, SHA-1, SHA-256)

GET https://api.threatvision.org/api/v2/samples/{hash}

Sample Response:

{
    "success": true,
    "risk_level": "high",
    "md5": "0f9d9438bd628418be4e6c59094c90bb",
    "sha1": "7b9324983131c38aca79625dcb3f9c2050b673d3",
    "sha256": "722bd8c64d76132e7163ffa9a9e22f4bfe42fe8dc5a0d2b7117a9f98b2285524",
    "first_seen": 1719872731,
    "size": 16359,
    "date": 1719876679,
    "meta": {
        "filename": {
            "original_filename": null,
            "pdb_strings": []
        },
        "document": {
            "code_page": ""
        },
        "exiftool": {
            "output": {
                "directory": "/",
                "file_name": "sample_path_in_docker",
                "file_size": "16 kB",
                "file_type": "sh script",
                "mime_type": "text/x-sh",
                "source_file": "/sample_path_in_docker",
                "file_access_date": "2024-07-31 22:25:37+0000",
                "file_modify_date": "2024-07-31 22:25:37+0000",
                "file_permissions": "rw-r--r--",
                "exif_tool_version": "11.88",
                "file_type_extension": "sh",
                "file_inode_change_date": "2024-07-31 22:25:37+0000"
            }
        },
        "file_hash": {
            "tlsh": "7572724ba119dc3b14eacc6e3363911d8a6b94eb806b5ff5fc65b43c442d04cb619ee8",
            "crc32": "91558144",
            "entropy": 5.27684211730957
        }
    }
}

ThreatQuotient provides the following default mapping for this action:

Feed Data Path	ThreatQ Entity	ThreatQ Object Type or Attribute Key	Published Date	Examples	Notes
.meta.exiftool.output.directory	Indicator.Attribute	Directory	N/A	/	N/A
.meta.exiftool.output.exif_tool_version	Indicator.Attribute	Exif Tool Version	N/A	11.88	N/A
.meta.exiftool.output.file_name	Indicator.Attribute	File Name	N/A	sample_path_in_docker	N/A
.meta.exiftool.output.file_permissions	Indicator.Attribute	File Permissions	N/A	rw-r--r--	N/A
.meta.exiftool.output.file_size	Indicator.Attribute	File Size	N/A	794 kB	N/A
.meta.exiftool.output.file_type	Indicator.Attribute	File Type	N/A	ZIP	N/A
.meta.exiftool.output.file_type_extension	Indicator.Attribute	File Type Extension	N/A	zip	N/A
.meta.exiftool.output.mime_type	Indicator.Attribute	Mime Type	N/A	application/zip	N/A
.meta.exiftool.output.source_file	Indicator.Attribute	Source File	N/A	/sample_path_in_docker	N/A
.risk_level	Indicator.Attribute	Risk Level	N/A	high	Updatable
.size	Indicator.Attribute	Size	N/A	813233	N/A
.md5	Related Indicator.Value	MD5	N/A	368a4cd9a9b34ada390c192157988921	N/A
.sha1	Related Indicator.Value	SHA-1	N/A	e0b5c5cd32f115b1ea4462bbbafc4cccef7d438f	N/A
.sha256	Related Indicator.Value	SHA-256	N/A	4bcedac20a75e8f8833f4725adfc87577c32990c3783bf6c743f14599a176c37	N/A

Risk Level Mapping

ThreatQuotient provides the following risk level mapping.

TeamT5 ThreatVision Value	ThreatQ value
undetected	Undetected
unknown	Unknown
low	Low
middle	Medium
high	High

Network IOCs

The operation will use different endpoints depending on if the given network IOC has related samples.

Network IOCs Summary

GET https://api.threatvision.org/api/v2/network/ips/{ip}/summary GET https://api.threatvision.org/api/v2/network/domains/{domain}/summary

Sample Response:

{
  "success": true,
  "analysis_status": true,
  "risk_score": 0,
  "risk_types": ["other"],
  "location": "",
  "adversaries": [],
  "attributes": [
    {
      "name": "Malware C2",
      "first_seen": "2022-12-15T15:34:06.071Z",
      "last_seen": "2023-04-14T05:54:22.454Z"
    }
  ],
  "services": [],
  "summary": {
    "whois": false,
    "related_adversaries": 0,
    "related_reports": 0,
    "related_samples": 10,
    "dns_records": 6,
    "osint": 0
  }
}

Network IOCs with Samples

If a given network IOC has related samples, they will be fetched using the following API:

GET https://api.threatvision.org/api/v1/network/ips/{ip}/summary GET https://api.threatvision.org/api/v1/network/domains/{domain}/summary

Sample Response:

{
  "success": true,
  "analysis_status": true,
  "samples": [
    {
      "sha256": "3252345b2640efc44cdd98667dbd25806ee2316d1e01eec488fd678e885aa960",
      "md5": "8f106544bfd4755d17a353064666426a",
      "adversaries": [],
      "malwares": [],
      "filename": null,
      "risk_level": "middle",
      "network_activity": true,
      "seen": false,
      "url": "https://api.threatvision.org/samples/3252345b2640efc44cdd98667dbd25806ee2316d1e01eec488fd678e885aa960"
    }
  ]
}

ThreatQuotient provides the following default mapping for this action:

Feed Data Path	ThreatQ Entity	ThreatQ Object Type or Attribute Key	Published Date	Examples	Notes
.risk_score	Indicator.Attribute	Risk Score	N/A	45	N/A
.risk_types[]	Indicator.Attribute	Risk Type	N/A	Cyber Espionage	N/A
.location	Indicator.Attribute	Location	N/A	Richardson, United States of America	N/A
.attributes[].name	Indicator.Attribute	Label	N/A	Malware C2	N/A
.adversaries[]	Indicator.Attribute	Related Adversary	N/A	N/A	N/A
.summary.related_samples[].sha256	Related Indicator.Value	SHA-256	N/A	3252345b2640efc44cdd 98667dbd25806ee2316d 1e01eec488fd678e885a a960	N/A
.summary.related_samples[].md5	Related Indicator.Value	MD5	N/A	8f106544bfd4755d17a3 53064666426a	N/A
.summary.related_samples[].adversaries[]	Related Indicator.Attribute	Related Adversary	N/A	N/A	N/A
.summary.related_samples[].malwares[]	Related Indicator.Attribute	Malware Family	N/A	N/A	N/A
.summary.related_samples[].filename	Related Indicator.Value	Filename	N/A	N/A	N/A
.summary.related_samples[].risk_level	Related Indicator.Attribute	Risk Level	N/A	Medium	Mapped to a standardized value using table Risk Level Mapping

PDF Guides

Document	ThreatQ Version
TeamT5 ThreatVision Operation Guide v1.1.0	5.20.0 or Greater
TeamT5 ThreatVision Operation Guide v1.0.0	5.20.0 or Greater
